Modular Air Surveillance Radar | 90° to 360° Coverage for Anti-Drone & Border Security

Product Overview
The HYH 223-1C1K is a compact, high-performance air surveillance radar designed for critical security applications. Utilizing Digital Beamforming (DBF) technology and phased array + pulse Doppler integration, this C-band radar delivers precise detection of low-RCS targets like drones (e.g., DJI Phantom 3/4, Mavic series) up to 1.2 km. Its modular design allows flexible deployment with single-panel 90° coverage or expanded configurations (dual-panel 180°, 3-panel 270°, 4-panel 360°), making it ideal for adaptive threat monitoring in diverse environments.

Key Features

• DBF Technology: Digitally control beam amplitude/phase for dynamic, shape-adaptive scanning.

• Lightweight & Compact: ≤10kg net weight, 445×300×400mm dimensions for easy stationary installation.

• High Precision: ≤10m distance accuracy, ≤1.0° azimuth accuracy, and ≤0.2m/s speed resolution.

• All-Weather Operation: Functions flawlessly in -40°C to +60°C with IP-rated rain, dust, sand, and corrosion resistance.

• Low Power Consumption: AC220V/40W operation for cost-effective 24/7 surveillance.

• Scalable Coverage: Expand azimuth coverage from 90° (single panel) to 360° (4-panel system).

Applications

• Airport perimeter security

• Border surveillance

• Critical infrastructure protection

• Communication electronic systems integration

Technical Specifications

Why Choose HYH 223-1C1K?

• Modular Flexibility: Customize coverage from 90° to 360° to match site-specific needs.

• Military-Grade Durability: Aluminum alloy packaging ensures rugged protection during transport and deployment.

• ISO-Certified Quality: Reliable performance compliant with international standards.

• Rapid Response: ≤1.5s data rate enables real-time threat tracking and countermeasure coordination.

     Sichuan Hongyinhui Technology Co. was founded in Chengdu in 2020, focusing on the electromagnetic spectrum monitoring and control field as the core, based on the system design, signal processing, hardware and software design and other core knowledge capabilities, to establish a more complete technical system of electromagnetic signal monitoring, identification, positioning and interference, and mastered high-fidelity technology, compressed perception technology, cognitive electromagnetic spectrum technology neural network approach, cross-polarisation interference technology and other key technologies. It has established a more complete technical system for monitoring, identification, positioning and interference of electromagnetic signals, and has mastered key technologies such as high-fidelity technology, compressed perception technology, neural network approach to cognitive electromagnetic spectrum technology, and cross-polarisation interference technology. Industry experts from relevant institutes and universities in the electronic countermeasures industry are the technical core, and have researched and developed the core key technologies with completely independent intellectual property rights, and established a brand-new product system.

     At present, the main products include: signal simulator, portable/vehicle-mounted/unmanned airborne reconnaissance jamming system, anti-radiation guide head, small radar simulation equipment, anti-null equipment, anti-null warning equipment and so on. Vast Exploration currently has a total of more than 50 employees, the core technical staff in the electronic warfare system integration related fields with more than 10 years of experience, master the spectrum monitoring and control of the field of system design, signal processing, hardware and software design and other core knowledge and ability.

     Our company takes miniaturisation/low-cost solutions as a breakthrough, and at this stage mainly serves various research institutes and listed companies, while accumulating relevant performance and company qualifications, precipitating technology, and gradually carrying out the R&D and delivery of large-scale electromagnetic spectrum systems.

     The company is committed to the system engineering design, broadband antenna, broadband microwave, signal processing, active interference, system integration, software engineering and other leading technologies applied to the national security, social security construction, and strive to become a domestic electromagnetic security field of private enterprises in the vanguard.
